PME-801LTA / 801LTB
Large Transformer Winding Machine
A heavy single-spindle winder for high- and low-voltage and large transformers, taking wire up to 3.0 mm with automatic spreading and stop.
- Spindles
- One
- Spindle speed
- 1,100 rpm
- Wire diameter
- 0.5–1.6 mm / 0.5–3.0 mm
- Power
- AC 200 V, 50/60 Hz
Features
- Ideal for high or low voltage transformer and large transformer
- Suitable for Wire size maximum to 3.0 mm
- Machine can be refitted to ground type
Specifications
| PME-801LTA | PME-801LTB | |
|---|---|---|
| No. of spindles | One | |
| Control mode | Microcomputer control, auto spreading and auto stop | |
| Memory capacity | 0–999 inputs (steps) | |
| Spindle speed | 1,100 rpm | |
| Wire diameter | 0.5–1.6 mm | 0.5–3.0 mm |
| Traverse width | 200 mm | |
| Main motor | Three-phase AC, 1 HP | |
| Traverse motor | Stepping motor | |
| Electric source | AC 200 V, 50/60 Hz | |
| Unit dimensions (L × W × H) | 390 × 580 × 430 mm | 700 × 520 × 600 mm |
| Unit weight | 52 kg | |
Specifications and design are subject to change without notice for improvements. Contact us to confirm the configuration for your parts.
