Station 04 · Soldering
PME-02AF
CNC Dip Soldering Machine, Auto Flux
Load by hand and the machine fluxes and dip-solders under CNC control, with 1,000-parameter memory and automatic dross cleaning.
- Cycle time
- 10–20pcs/8sec
- Inner tank
- 300(L) × 100(W) × 60(H) mm
- Power
- AC 220V, 50/60Hz, 2000W
- Weight
- 60 kg
Features
- Applicable for Vertical or Horizontal Coil or Relay component soldering work
- Adopted with CNC controller system, it can store up to 1000 parameters memory harmony with stepping motor
- Auto dross clean, adjustable for soldering height
- Heater pipe is a single unit and can be easy exchange & maintenance
- Adopted with titanium solder pot, sustains high temperature, max. 600°C
Specifications
| Cycle Time | 10–20pcs/8sec |
|---|---|
| Traverse | Max. 76 mm (Stepping Motor) |
| Air Pressure | 5 kg/cm² |
| Electric Source | AC 220V, 50/60Hz, 2000W |
| Inner Tank | 300(L) × 100(W) × 60(H) mm |
| Unit Dimension | 550(L) × 600(W) × 535(H) mm |
| Unit Weight | 60 kg |
| Optional Device | Dragging mechanism |
Process flow
Process flow
- Manual load / NG unload
- Auto flux
- Auto solder
Specifications and design are subject to change without notice for improvements. Contact us to confirm the configuration for your parts.
