Station 04 · Soldering
PME-05LVB
Choke Coil Dip Soldering Machine
Twin vibratory bowls feed choke coils through flux dipping, dip soldering and unloading, two products at a time.
- Control
- Servo Motor & PLC
- Power
- AC 220V, 50/60Hz
Features
- Applicable for Choke coil soldering work
- Fully automatic feeding material, flux dipping, dip soldering and unloading
- Twin vibration bowls that allow two different kinds of products be simultaneously loaded and soldered
- Programmable angle rotation for dip soldering
- Allowed custom design according to customer's special soldering request and specification
- Functional, stable, high efficiency, labor cost saving and simple operation
Specifications
| Operation | Control Touch Panel Interface |
|---|---|
| Control | Servo Motor & PLC |
| Air Pressure | 4-6 kg/cm² |
| Electric Source | AC 220V, 50/60Hz |
| Unit Dimension | 920(L) × 700(W) × 1300(H) mm |
| Vibration Bowl Table Size | 900(L) × 400(W) × 1100(H) mm |
Specifications and design are subject to change without notice for improvements. Contact us to confirm the configuration for your parts.
